GFRP混合配筋偏心受压柱正截面承载力计算方法

打开文本图片集

中图分类号：TU375.3 文献标志码：A 文章编号：1008-0562（2025）04-0419-11

WANGTan，YINJunbo，LILiwei，etal.Calculationmethodof normalsectionbearingcapacityofGFRPhybridreinforced eccentricallyopredos[J]oalofaogcalUivesityaturaliee），4（4）：1-9O/ j.issn.1008-0562.20240209

Calculation method of normal section bearing capacity of GFRP hybrid reinforced eccentrically compressed columns

WANG Tan12，YINJunbo’，LILiwei'，ZHOU Zhijiel，YANGFan1，JINMu'，WUNing³，DAI Suliang4

（1. College of Civil Engineering， Changchun Institute of Technology， Changchun 13o012， China; 2.JilinProvincialKeyLaboratoryofCivil EngineeringEarthquakeResistanceandDisasterReduction， Changchun 13o012， China;3.China Construction Third Engineering Bureau Urban Construction Company Limited， Changchun 130o12， China; 4.The 23rd Metallurgical Construction Group Company Limited of Minmetals， Changsha 41ol16， China）

Abstract：This study investigated the method forcalculating the normal section bearing capacityof glas fiber reinforced polymer （GFRP） hybrid reinforced eccentric compression column.Based on the experiments research， the finite element software was used to cary out parametric analysis，defined the main parameters in the formula， and refined the role of thecore column on the bearing capacity.The calculation formula and design process of normal section bearing capacity under three failure modes ofcompresson failure，yield-compression failure and yield-tension failure were established.The calculated value ofthe formula was in good agreement with the actual value.The formulacan be applied to the Various kinds fiber reinforced polymer of FRP hybrid reinforced eccentric compression columns with large eccentricity，and provides design basis and theoretical reference for the engineering application of this kind of hybrid reinforced columns.

Key words：hybrid reinforced;glass fiber reinforced polymer bars； eccentrically compressed column； finite element analysis; calculation of bearing capacity; compressive failure

0 引言

钢筋混凝土结构具有结构性能好、成本低，以及材料易取等优点，在建筑行业中得到广泛应用。（剩余15492字）
