插座外壳注塑模具设计

打开文本图片集

中图分类号：TQ320.66 文献标志码：A

Abstract：The mold design and material selection for the high-voltage connector socket housing directly affect the reliability of the equipment. This paper proposes a mold design scheme based on carbon fiber composite materials. By optimizing the gating system with a bul-horn latent gate and combining a surrounding cooling circuit with a well-type cooling circuit，the molding efficiency is significantly improved. Experimental results indicate that the optimized pouring time is reduced to 7.22s ，with a melt shear rate of 4×105s-1 and a filling rate exceeding 98% . Moreover，the corrosion potential of the carbon fiber composite material remains stable at -0.11V ，while its tensile strength （209MPa， ）and flexural strength（268 MPa ） surpass those of traditional metal materials. When the carbon fiber content is increased to 30% ， the warpage of the plastic part at the vertical and parallel cross-sections is reduced to（204号 0.1414mm and 0.1413mm ，respectively，and the service life of the mold is extended to 8 years.This study provides a technical reference for the design of injection molds for highprecision socket housings. This study provides technical reference forthe design of highprecision injection molds for socket housings.

Key words：electrical equipment； housing mold;carbon fiber composite material； bull horngate;casting system

0 引言

随着全球经济的快速发展，电力行业也取得了显著发展，电力电气设备的大面积应用，有效促进了电力机制的改革与完善[1]。（剩余8510字）
