一种用于干扰试验的高压脉冲模拟器设计

打开文本图片集

摘要：通过原理分析、工程计算和建模，设计一种高压脉冲模拟器，用于模拟电磁环境中瞬时高压信号的干扰试验。该高压脉冲模拟器利用高压真空继电器进行极性转化，高压水银开关实现放电。经测试，该高压脉冲模拟器实现了ns级上升沿，脉宽1µs，带载50Ω，幅值1.5 kV的高压脉冲输出。

关键词：安全测试；电磁环境；高压脉冲；模拟器；干扰试验

中图分类号：TP271;TP277 文献标志码：A 文章编号：1674-2605（2023）06-0005-04

DOI：10.3969/j.issn.1674-2605.2023.06.005

Design of a High-voltage Pulse Simulator for Interference Testing

YANG Maochang1PAN Shaoci2

（1.GuangdongZhongzhi Testing Technology Co.， Ltd.， Guangzhou 510663，China

2.Institute of Electronic Products and Electrical Appliances， Guangdong Academy of Sciences，Guangzhou 510400， China）

Abstract：Design a high-voltage pulse simulator through principle analysis， engineering calculation， and modeling to simulate interference tests of instantaneous high-voltage signals in electromagnetic environments. The high-voltage pulse simulator utilizes a high-voltage vacuum relay for polarity conversion and a high-voltage mercury switch for discharge. After testing， the high-voltage pulse simulator has achieved a ns level rising edge and a pulse width of 1 μs. High-voltage pulse output with a load of 50 Ω and an amplitude of 1.5 kV.

Keywords：security testing; electromagnetic environment; high-voltage pulse; simulator; interference test

0引言

许多工业和商用设备，如电梯、空调、灯具、影视设备等，出厂前都要进行安全测试和可靠性测试。（剩余3788字）
