高比例光伏台区分布式协同多节点电压控制技术研究

打开文本图片集

DOI：10.16652/j.issn.1004-373x.2026.10.028

关键词：分布式光伏；电压控制；多设备协同；调压装置；低压台区；电压越限；配电网

中图分类号：TN913.3-34；TM72

文献标识码：A

文章编号：1004-373X（2026）10-0191-08

Research on distributed collaborative multi-node voltage control technology for high-proportion PV transformer district

Gao Yunhao 1，2 ， Li Xiao 1 ， Zhang Hui 1 ， He Jinwei 2

School of Electrical and Control Engineering， North University of China， Taiyuan 030051， China; 2. School of Electrical and Information Engineering， Tianjin University， Tianjin 300072， China）

Abstract： With the large-scale integration of high-proportion distributed photovoltaics （PV） into low-voltage transformer districts， voltage and power flow violations have grown increasingly prominent. The traditional centralized head-end voltage regulation method relies on a single large-capacity device to manage voltage for all nodes along the line， but in PV transformer district with severe reverse power flow， forcibly adjusting the voltage to meet the standard at the end nodes may cause voltage violations at the head-end nodes， making it difficult to satisfy the differentiated voltage regulation requirements among multiple nodes. To address this issue， a multi-device coordinated voltage regulation method is proposed. Based on line topology and load distribution， the power line at the transformer districts is split into two sections （front and rear）. Some capacity of the head-end and end-end voltage regulating devices are deployed separately in each section， transforming the full-line voltage regulation task that is originally required to be independently undertaken by a single traditional voltage regulating device into segmented collaborative regulation by two voltage regulating devices. This multi-device coordinated voltage regulation method that decomposes the voltage regulation task can not only reduce the system's total capacity requirement for voltage regulation devices， but also enhance the flexibility of voltage adjustment， ultimately achieving wide-range regulation with small-capacity equipment.

Keywords： distributed PV; voltage control; multi-device coordination; voltage regulation device; low voltage transformer district; voltage violation; distribution network

0 引言

在“双碳”目标驱动下，分布式光伏开始大规模接入配电网，但规模化并网也引发了低压台区电压与潮流越限等问题 [1-2] 。（剩余9305字）
