混合式TOF传感宠物狗呼吸监测系统的设计

打开文本图片集

关键词：TOF传感器；非接触式监测;宠物呼吸频率；心力衰竭犬；LabVIEW中图分类号：TP212 文献标识码：Adoi：10.37188/OPE.20253320.3180 CSTR：32169.14.OPE.20253320.3180

Abstract：To addressthe clinical need for continuous respiratory rate monitoring in dogs with heart failure，this study developed a novel non-contact respiratory monitoring system based on Hybrid TOF（optical time--flight） sensing. A hybrid single-point/array TOF sensing architecture was proposed，incorpo rating a spatial adaptive monitoring model to accommodate varying pet postures. An STM32-embedded platform enabled sensor synchronization raw signal preprocessng，while a LabVIEW-based host computer implemented real-time respiratory waveform analysis algorithms. Optical calibration tests optimized array TOF ranging parameters. Testing on small-sized dogs under static conditions demonstrates a respiratory rate measurement error ⩽2 breaths per minute （BPM）. The LabVIEW interface enables realtime visualization respiratory waveforms BPM values，confirming the feasibility optical TOF sensing for vital sign monitoring. The hybrid TOF system achieves high-precision static respiratory monitoring in dogs through optical measurement optimization spatial adaptive strategies，which provides a miniaturized，low-cost bionic optical solution for veterinary medical applications.

Key words： TOF sensor; non-contact monitoring； pet respiration rate; dogs with heart failure; LabVIEW

1引言

近年来，社会结构的深刻变革推动养宠群体持续扩容并呈现多元化特征，涵盖单身青年、空巢老人、育前家庭等不同群体。（剩余15413字）
