热泵防冻液低温真空再生特性

打开文本图片集

中图分类号：TQ028 文献标志码：A 文章编号：1008-0562（2026）01-0115-08

Hany SeragEL-MESERY'，MohamedQENAWY'，Tilahun Seyoum WORKNEH3

Low-temperature vacuum regeneration characteristics of heat pump antifreeze

HU Zicheng'，YI Xintai’， HAN Yuchen'， GUAN Haiqing²， XU Rongjin'， Hany Serag EL-MESERY'， MohamedQENAWY'，TilahunSeyoumWORKNEH

（1.School of Energy and Power Engineering， Jiangsu University， Zhenjiang 212o13， China;2.PanasonicR&D Center Suzhou Company Limited，Suzhou 215oo0， China;3.School of Engineering， University of KwaZulu-Natal，Pietermaritzburg 32o1，South Africa）

Abstract：To addressthe high energy consumption issue in the regeneration of antifreeze for heat source tower heat pump，a low-temperature vacum solution regeneration system based on heat pump was designed and constructed，and experimental researchon itsregenerationcharacteristicswas carred out.Theresults show that the optimal evaporation temperature and condensation temperature of the heat pump are 30°C and 55∘C （204号 respectively under the design conditions.During the regeneration proces，the water production rate of the system increased by2 percentage points when the solution filling amount increased from 20kg to 80kg .When the solution concentration increased from 10% to 30% ，the water production rate of the system decreased by 1.2 percentage points.When the vacuum degree increases from 84% to 93% ，the water production rate of the system increases by 47.3 percentage points.The system can operate continuously and stably，with daily water production of 1.4t and unit energy consumption evaporation of 6.33kg/（kW⋅h） . The research conclusion can provide reference for low energy consumption and high efficiency regeneration of solutions.

Keywords：antifreeze solution; low temperature vacuum regeneration； heat pump; solution regeneration; regenerationcharacteristic

0 引言

热源塔热泵是夏热冬冷地区广泛应用的无霜空气源热泵系统，其冬季运行时使用防冻液避免室外蒸发器结霜。（剩余13260字）
